| Brand | -50℃ to 80℃ | Code | Muilt-core | | Core | Muilt | conductor | copper | | Nominal voltage U0/U | 2000V | Temperature (°C) - flexing | -40°C till +90°C | | Temperature (°C) - fixed | - | Color | Yellow/Blue | | MOQ | 300M/Roll | | |
| Brand | KMCABLE | | Product Name | ROV tether buoyancy Underwater cable Waterproofing Multicore floating electrical power Cables | | Application | As a new type of waterproof wire the waterproof performance of the cable is more excellent,Submarine zero buoyancy cable cab be designed according to the actual length of the customer is specific and easy to use. |
| Conductor |
Bare copper conductor, to DIN VDE 0295 cl.5, fine wire, BS 6360 cl.5, IEC 60228 cl.5 |
| | Core | Muilt-core | | Temp |
-50℃ to 80℃ | | Insulation | Polyethylene | | Sheath | Foaming PUR jacket | | Sheath colour | Blue/Yellow/Orange | | Packaging | Meter marking |
| Test voltage : |
300V/300V, 300V/500V | | Temperature range : |
-50℃ to 80℃ | | Nominal voltage : |
2000V |

| Relaed parameters | | Working temperature | -50℃ to 80℃ | | Strength members | High strength rakevla bulletproof wire,tensile 150KG | | Wrapping material | High quality non-woven fabric | | Rated voltage | 300V/300V,300V/500V | | Test voltage | 2000V | | Signal transmission distance | Less than 80 meters | | Fiber optics transmission distance | Less than 10,000 meters |
| CAT5E | CAT6 | | Banwidth | 100Mhz | 250Mhz | | Disturbance resistant | Normal | Good | | Suitable for | 100BASE-TX(Fast Ethernet) | 1000BASE-TX(Gigabit Ethernet) | | Theoretical download | 12.8M/s | 128M/s |

|
