High Quality PUR Insulated JZ-HF-CY High Flexible Cable Muilt-core Screen Drag Chain Cable

Price：
$1.00
Consult immediately Reservation Now
Product Details
Brand KMCABLE Code Muilt-core
Core Muilt conductor copper
Nominal voltage U0/U U0/U 300/500 V Temperature (°C) - flexing -20°C  to  +80°C
Temperature (°C) - fixed -40°C  to  +80°C Color Gray
MOQ 500meter


Product Information





Brand    KMCABLE
Product Name    High Quality PUR Insulated JZ-HF-CY High Flexible Cable Muilt-core Screen Drag Chain Cable
Application    This is a highly robust and tare and abrasion resistant cable with excellent resistance properties to mineral oils and cooling fluids, thus making it an ideal choice for installation in most types of industrial machinery as well as in steel works and rolling mills, etc. in fact, wherever you may need a cable to cope with especially critical situations. Easy to install, thanks to its high degree of flexibility. Its high abrasion resistance and good flexing ability make it quick and easy to install and, with its low bending radius, ideal for use with cable trays. This screened cable is ideal for use in data signal transmission free from interferences for measurement and control engineering technology.JZ-HF-CY/PUR cables are ideal for use in the machine tool industry, in robotics and machine production and anywhere where high flexibility is essential. These cables have shown excellent performance in combination with standard cable trays. These cables are suitable for flexible use for medium mechanical stresses with free movements. The dense screening assures disturbance-free transmission of all signals and impulses.





Product Mix






Conductor

Bare copper conductor,

extra fine wire acc. to

DIN VDE 0295 cl.6, col. 4 / IEC 60228 cl.6


Core insulation    Special PVC
Core identification

Core identification to DIN VDE 0293

black cores with continuous white

numbering

Outer sheath    Special PUR
Sheath colour    Grey
Packaging    Meter marking



Technical Parameter





Test voltage :

4000 V

Nominal voltage :

U0/U 300/500 V

Temperature range :

flexing   -20°C   to   +80°C

fixed installation   -40°C   to   +80°C

Minimum bending radius :

flexing 10x outer Ø

fixed installation 5x outer Ø





Product Details




jz-hf-cy-muilt-core-screen-drag-chain-cable08.jpgjz-hf-cy-muilt-core-screen-drag-chain-cable07.jpgjz-hf-cy-muilt-core-screen-drag-chain-cable01.jpg
