| Brand | KMCABLE | Code | Muilt-core | | Core | Muilt | conductor | copper | | Nominal voltage U0/U | 300/500V | Temperature (°C) - flexing | -5 to +80℃ | | Temperature (°C) - fixed | -40 to +80℃ | Color | Gray | | MOQ | 500meter | | |
| Brand | KMCABLE | | Product Name | KMCABLE Flexible Control Cable Muilt-core PVC Insulated JZ-500 Flexible Control Cable | | Application | These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as connecting and control cables in tool machines, conveyor belts, assembly lines, plant engineering, AC technology, steel production and other manufacturing environments. Selected PVC compounds guarantee good flexibility as well as an economic and fast installation. |
| Conductor | Bare copper-conductor, to DIN VDE 0295 cl.5, fine-wire, BS 6360 cl.5, IEC 60228 cl.5 |
| | Conductor construction | GN-YE conductor, 3 cores and above
in the outer layer | | Core insulation | Special PVC | | Core identification | Core identification to DIN VDE 0293black cores with continuous whitenumbering (also available in othercolours on request) | | Outer sheath | Special PVC | | Sheath colour | Grey | | Packaging | Meter marking |
| Test voltage : | 4000 V | | Nominal voltage : | U0/U 300/500 V | | Temperature range : |
flexing -15°C to +80°C fixed installation -40°C to +80°C | | Minimum bending radius : |
flexing 7,5x cable Ø fixed installation 4x cable Ø
|

|
